9.66 Inch AHD Mirror & Reverse Camera Kit
9.66 Inch AHD Mirror & Reverse Camera Kit
Features:
9.66 Inch high resolution LCD mirror monitor with rubber clip-on mirror mounts for simple and secure installation onto the existing rear-view mirror.
The reverse camera features a 144 degree wide viewing angle for reducing blind spots.
Includes an 8m long rear camera cable to connect the rear camera to the mirror monitor.
Live streaming function enables the monitor to display rear vision while driving, ideal for vehicles with limited rear vision
Reverse trigger circuit displays reverse image & parking gridlines when reverse gear is engaged.
Mirror Monitor Specifications:
Monitor Size: 9.66 Inch
Monitor Resolution: 1280*320 pixel
Mounting Type: Clip on rear view mirror
Input Voltage: 5V 3A (12/24V Accessory power adaptor Included)
Video Input: 1 x 2.5mm socket (To connect reverse camera)
Monitor Size: 72mm(H) X 257mm(W) X 38mm(D)
USB/Power Input: Yes (Micro USB)
Power Adaptor Voltage: 12/24V
Input Voltage: 5V 3A
Hard Wire Kit: Optional (RVS966-HWA)
Rear Camera Specifications
Mount Type: Surface mount
Camera Resolution: 1080P
Camera Angle: 144 Degree
Image Sensor: CMOS
Input Voltage: 12V
Connection Type: 4 Pin
Cable Length: 7.5 Metres
Parking Gridlines: Yes. (Must connect the reverse trigger wire on the video cable to the reverse gear circuit).
Camera Size: 26mm (H) x 45.5mm (W) x 40mm (D)
Kit Contents:
9.66 Inch Mirror Monitor
AHD Butterfly Reverse Camera with mounting screws and double sided tape
7.5 Metre Camera Extension Cable With Trigger Wire
12V/24V Accessory Power Adaptor
Rubber Mirror Mounting Clips & Mirror Protecting Pads
Packaging: Display gift box
Optional Accessories (sold separately)
RVS966-07M - 7.5m Camera extension cable for longer vehicle installation requirements
RVS966-15M - 15m Camera extension cable for longer vehicle installation requirements
RVS966-HWA - Hard wire cable available for hard wire connection to the vehicle fuse box instead of using the included accessory socket power adaptor. (Fitted with Mini blade fuses)
