7 Inch Analog High Definition (AHD) LCD Rearview Screen & CMOS Camera Pack
This high resolution 3 Channel TFT-LCD monitor is ideal for multiple camera applications for full screen viewing. Includes front panel touch buttons with a large removable sun visor and is ideal for Caravans and Truck installations where a large viewing screen required.
AHD supports 720P, 960P and 1080P video resolutions.
Screen:
7 Inch TFT-LCD display
Aspect Ratio: 16:9
Video System: (AUTO) PAL & NTSC
Resolution: 1024 (RGB) x 600 Pixel
3 HD Camera Inputs with 3 triggered inputs for each camera
Supports 720P @ 25/30, 720P @ 50/60, 1080P @ 25/30
Supplied with 6 metre 4 pin to 4 pin extension cable for connection between screen and camera
Dash mountable with U shaped bracket
Screen sun visor
Illuminated touch front panel buttons
4 Pin water-resistant lockable camera connections
IR remote
Image options: UP/Down and Left/Right (mirror)
Operating Temperature: 0°C /+60°C
Operating Voltage: 12V to 24V DC (+/- 10%)
Current Consumption: 5W
Size: 180mm W x 121mm H x 24mm D
Packaging: Display box
Cabling:
Kit contains
1 x 6M 4 Pin extension cable
Camera:
Heavy Duty PAL CMOS Truck/Bus/Caravan Camera
This all metal waterproof construction CMOS camera is ideal for trucks or buses where heavy duty application is required. Operates on 12V or 24V vehicles and includes built in IR LEDs for excellent night visibility.
1/3 Inch Sony PAL CMOS Image processor
140° Horizontal Viewing angle
Resolution: 1280x720
IR LEDS: 18 IR Led
0.1 LUX illumination (night mode)
Operating Voltage: 12V
Sun Visor Included
Material: Aluminium alloy shell
S/N ratio: >48db
Waterproof rating to IP68
Video output: 1Vp-p 75 ohm composite
Supplied with 0.6m 4pin water resistant lockable connector
Dimensions: 86.5mm W x 77mm H x 75mm D
THIS KIT Will WORK WITH THE FOLLOWING CABLES:
Woza Cable Kit: RVEW
Extension Cables: RVEW, RVE05, RVE07, RVE10, RVE15, RVE20
Important information:
AHD cameras will not work on non-AHD screens.
Non-AHD cameras will not work with AHD screens.
