6-Circuit ST Blade Fuse Block with Negative Bus & Cover

6-Circuit ST Blade Fuse Block with Negative Bus & Cover

The 6-Circuit ST Blade Fuse Block with Negative Bus and Protective Cover provides a compact and efficient solution for organizing and protecting multiple electrical circuits. Designed to consolidate branch circuits and eliminate the need for numerous in-line fuse holders, this fuse block simplifies wiring installations in marine, automotive, RV, and other DC electrical systems.

Featuring a positive distribution bus and integrated negative bus, the unit allows for clean and professional wiring management. Constructed with tin-plated copper buses and fuse clips for superior corrosion resistance and conductivity, it delivers reliable performance in demanding environments. The clear protective cover enhances safety while allowing easy fuse inspection, and the included label sets ensure quick circuit identification.

Features
Consolidates multiple branch circuits into a single fuse block
Integrated negative bus for simplified wiring
Clear protective cover for added safety and fuse visibility
Corrosion-resistant tin-plated copper buses and fuse clips
Compatible with ring or snap fork type terminals
Accepts standard ATO and ATC blade fuses
Suitable for 24-hour circuits
Includes two label sets and mounting screws
Fuses sold separately

Specifications
Number of Circuits: 6
Maximum Voltage: 32V DC
Maximum Total Current: 100A
Maximum Current per Circuit: 30A
Bus Material: Tin-Plated Copper
Terminal Type: Ring or Fork
Fuse Type: ATO / ATC Fast-Acting Blade Fuses
Positive Terminal Posts: M5
Negative Terminal Posts: M5
Load Terminal Posts: M4
Application: Marine, RV, Automotive, and DC Electrical Systems

Dimensions
Length: 124 mm
Width: 84 mm
Height: 39 mm
