Premium OEM Style 9.66 Inch Replacement Mirror & Camera Kit To Suits Most Volkswagen Vehicles

This mirror features a 9.66 inch full screen display that captures the crystal clear images from the rear view camera.
The 9.66 inch full screen automatically comes on once reverse is selected.
Includes heavy duty 120 degree rear camera with 2 mouting option, butterfly mount or glass mount
Includes an 6m long rear camera cable to connect the rear camera to the mirror monitor.
SKU
RVS966VW02
Low In stock
$599.95
Fast Shipping
Australia Wide
Australian Owned
& Operated
Secure Checkout
Multiple Payment Options
This mirror features a 9.66 inch full screen display that captures the crystal clear im...
The 9.66 inch full screen automatically comes on once reverse is selected.
Includes heavy duty 120 degree rear camera with 2 mouting option, butterfly mount or gl...
Includes an 6m long rear camera cable to connect the rear camera to the mirror monitor.

Product Overview

Premium OEM Style 9.66 Inch Replacement Mirror & Camera Kit with Auto Brightness Includes mirror mount bracket that suits most Volkswagen vehicles

Key Features

  • This mirror features a 9.66 inch full screen display that captures the crystal clear images from the rear view camera.
  • The 9.66 inch full screen automatically comes on once reverse is selected.
  • Includes heavy duty 120 degree rear camera with 2 mouting option, butterfly mount or glass mount
  • Includes an 6m long rear camera cable to connect the rear camera to the mirror monitor.
  • Reverse trigger circuit displays reverse image & parking gridlines when reverse gear is engaged.

Mirror Monitor Specifications

Monitor Size9.66 Inch MIPI IPS
Monitor Resolution 1280*320 pixel
Mounting TypeOEM mirror mount bracket (different bracket option available, sold separately)
Input Voltage5V 3A (12/24V Accessory power adaptor Included)
Video Input1x To connect reverse camera
Monitor Size81.6mm(H) X 253mm(W) X 48.3mm(D)
Power Adaptor Voltage12/24V
Input Voltage5V 3A

Rear Camera Specifications

Mount TypeSurface mount or glass mount
Camera Resolution1080P AHD
Camera Angle120 Degree
Input Voltage12V
Connection Type4 Pin
Parking Gridlines Yes
Camera Size23.5mm (H) x 23.5mm (W) x 34mm (D)

Kit Contents

  • 9.66 Inch Mirror Monitor
  • AHD Reverse Camera
  • Camera Extension Cable With Trigger Wire
  • OEM mirror mount bracket
  • Packaging:  Display gift box
