Reverse Camera with 5 Inch LCD Screen

Includes selectable options: PAL/NTSC video format, parking guide lines and reverse mirror imaging.
Camera also includes butterfly mount and flush mount and has a Waterproof IP68 rating.
Ideal for a wide range of vehicles wanting a safety solution. Rear, front or side mount applications.
RCB170 Camera Specifications:
SKU
RVS50P
Low In stock
$211.95
Add to Compare
Quick Overview

Reverse Camera with 5 Inch LCD Screen

Fast Shipping
Australia Wide
Australian Owned
& Operated
Secure Checkout
Multiple Payment Options
Includes selectable options: PAL/NTSC video format, parking guide lines and reverse mir...
Camera also includes butterfly mount and flush mount and has a Waterproof IP68 rating.
Ideal for a wide range of vehicles wanting a safety solution. Rear, front or side mount...
RCB170 Camera Specifications:

Product Overview

5 Inch Rearview LCD Monitor With Butterfly/Flush Mount Camera (RCB170) This kit provides a complete safety package incorporating a 5 inch screen and reverse camera in a convenient pack. 5 Inch rearview LCD monitor - (RVS50) This 5 Inch screen is compatible with all our cameras models and has a built-in sunvisor Fully adjustable ball joint bracket which is dash mountable with 3M adhesive tape. Has two video inputs and includes 12V power cable. RVS50 Screen Features: High definition LCD display 360 Degree adjustable mount 2 x RCA Video inputs (AV2 (White) has priority over AV1 (Yellow) Specifications: Screen Size: 5 Inch LCD Display Video System: PAL / NTSC Mode: 4:3 or 16:9 Resolution: 800(H)*400(V) Video Input: 1.0V±0.5Vp-p 75O Auto Switching: V1 & V2 (Priority) Operating temperature: -10°C - +50°C Working Voltage: DC12V (+/-10%) Consumption: 130mA±10% CMOS Reverse Camera Butterfly Mount - (RCB170) This miniature butterfly/flush mount camera is a truly universal solution for multipurpose vehicle installations. Model Strengths: Universal Zinc Alloy Housing Miniature Side Mounting Option PAL / NTSC Selectable* (By default set to PAL. To select NTSC cut the wire) Parking Guide Lines* Mirror Image*

Key Features

  • Includes selectable options: PAL/NTSC video format, parking guide lines and reverse mirror imaging.
  • Camera also includes butterfly mount and flush mount and has a Waterproof IP68 rating.
  • Ideal for a wide range of vehicles wanting a safety solution. Rear, front or side mount applications.

Specifications

Screen Size5 Inch LCD Display
Video SystemPAL / NTSC
Mode4:3 or 16:9
Resolution800(H)*400(V)
Video Input1.0V±0.5Vp-p 75O
Auto SwitchingV1 & V2 (Priority)
Operating temperature-10°C - +50°C
Working VoltageDC12V (+/-10%)
Consumption130mA±10%
CMOS Reverse Camera Butterfly Mount - (RCB170)
This miniature butterfly/flush mount camera is a truly universal solution for multipurpose vehicle installations.
Model Strengths
Universal
Zinc Alloy Housing
Miniature
Side Mounting Option
PAL / NTSC Selectable* (By default set to PAL. To select NTSC cut the wire)
Parking Guide Lines*
Mirror Image*
Features
Includes selectable optionsPAL/NTSC video format, parking guide lines and reverse mirror imaging.
Camera also includes butterfly mount and flush mount and has a Waterproof IP68 rating.
Ideal for a wide range of vehicles wanting a safety solution. Rear, front or side mount applications.
RCB170 Camera Specifications
Image SensorCMOS (PC3089)
Video SystemPAL or NTSC (Selectable)
Scanning area4.80mm*3.73mm
Resolution756(H)*504(V)
Horizontal Resolution600 TVL
Electronic Shutter1s-1/10000(S)
SNR=46.5dB
Min Illumination0.01Lux
Video Output1.0V±0.5Vp-p 75O
View Angle170°
Working VoltageDC9V-15V±0.5V
Consumption100mA±10%
Waterproof RatingIP68
PackagingDNA Gift box with sleeve
