In stock

Reversing Backup Alarm Squawker With Left Turning Message - Black

$172.95 RRP
SKU
RBA020

Buzzer Sound: Squawk-Squawk-Squawk-Squawk
Warning Message 1: Squawk Squawk, caution, vehicle turning left
Warning Message 2: Beep, Beep, warning, this vehicle is reversing
Extra functions: Half dB / Mute / Output trigger for warning lights

Reversing Backup Alarm Squawker With Left Turning Message - Black

This reversing back up squawker alarm is perfect for use in cars, utes, light vans, trucks, buses, coaches, forklifts and other machinery.
The unit emits a loud buzzer that alerts pedestrians when the vehicle is reversing. It also has an spoken alert message to advise if the vehicle is turning left, as well as many other functions.

Buzzer Sound: Squawk-Squawk-Squawk-Squawk
Warning Message 1: Squawk Squawk, caution, vehicle turning left
Warning Message 2: Beep, Beep, warning, this vehicle is reversing
Extra functions: Half dB / Mute / Output trigger for warning lights

Fully waterproof and withstands extreme temperatures.
Easy installation using the universal mounting bracket design.

Specifications:
Sound Level: 90 ± 3dB
Sound: Refer above to notes
Voltage Range: 12-24 VDC
Max Current Consumption: 0.2A
Max Output Current: 1 Amp
Power Connection: Positive & negative wires
Housing: Nylon casing with 4 x mounting hole points
Size: 105mm L x 40mm D x 74mm H
Hole Centre: 75mm - 85mm
Colour: Black
Packaging: White Box


Wiring Information:
Red Wire: Power Input (12/24V). Connect to ACC (12/24V).

Black Wire: Ground. Connect to chassis.

Violet Wire: Left Turn Alarm Trigger (+). Connect to the left indicator or side detection system with positive output trigger.

Green Wire: Mute Wire. Connect to the right indicator when the alarm is used for left turn (mute for hazard lights). Connect to headlights or side lamps for mute night shift function.

Brown Wire: Reverse Alarm Trigger (+). Connect to reverse light.

Blue Wire: Reverse Alarm Trigger (-). Connect to back detection system with negative output trigger.

White Wire: Reverse Alarm Trigger with Double Engage Night Shift Function.
(+) Connect to reverse light, double engage reverse gear within 2 seconds the sound pressure will be lowered by 50%.
Do not connect the brown wire when this white wire is connected.

Orange Wire: Night Shift Wire (1/2 decibel).
A. Connect to the headlights or side lamps. The sound pressure of the alarm will be lowered by 50% when the headlights/side lamps are turned on.
B. Connect to a switch button for manual night shift function.

Yellow Wire: Output Trigger (-). Connect to the ground wire of extra warning lights. The alarm will give visual warning as well as audible warning.
