Round Panel Mount 12/24V Digital Temperature Gauge

LED Temperature meter with temperature sensor
Ideal for monitoring the temperature of your vehicle fridges or even your amplifier
The mounting hole is suitable for standard panel frames or direct panel installation.
Designed to mount into any of the following PA series sockets:
SKU
PATEMP
In stock
$37.95
Fast Shipping
Australia Wide
Australian Owned
& Operated
Secure Checkout
Multiple Payment Options
LED Temperature meter with temperature sensor
Ideal for monitoring the temperature of your vehicle fridges or even your amplifier
The mounting hole is suitable for standard panel frames or direct panel installation.
Designed to mount into any of the following PA series sockets:

Round Panel Mount 12/24V Digital Temperature Gauge

LED Temperature meter with temperature sensor
Ideal for monitoring the temperature of your vehicle fridges or even your amplifier
The mounting hole is suitable for standard panel frames or direct panel installation.

Specifications:
White LED with 3 digit display
Temperature probe length: 2 metres
Max Temperature: 80 degrees Celsius
Input voltage: 12V-24V
Terminals: Positive & Negative 6.4mm terminals on rear
Mounting opening: 29mm Diameter
Size: 36.5mm Diameter x 27.5mm Deep
Colour: Black
Packaging: Poly bag with barcode sticker


Designed to mount into any of the following PA series sockets:
Empty flush mount plate sockets
PA003 & PA004

Any of the following power sockets that have a round 29mm socket.
Simply remove the fitted socket and install this temperature gauge in its place.
PA100, PA101, PA102, PA105, PA105
PA200, PA201, PA202, PA203
PA300, PA301, PA302, PA304
PA400, PA401, PA402, PA403
PA501, PA502, PA503, PA504
PA601

Specifications

White LED with 3 digit display
Temperature probe length2 metres
Max Temperature80 degrees Celsius
Input voltage12V-24V
TerminalsPositive & Negative 6.4mm terminals on rear
Mounting opening29mm Diameter
Size36.5mm Diameter x 27.5mm Deep
ColourBlack
PackagingPoly bag with barcode sticker
Designed to mount into any of the following PA series sockets
Empty flush mount plate sockets
PA003 & PA004
Any of the following power sockets that have a round 29mm socket.
Simply remove the fitted socket and install this temperature gauge in its place.
PA100, PA101, PA102, PA105, PA105
PA200, PA201, PA202, PA203
PA300, PA301, PA302, PA304
PA400, PA401, PA402, PA403
PA501, PA502, PA503, PA504
PA601
