Heavy Duty Type-C & USB Socket

This easy to install socket system is fitted with Type-C and USB charger sockets

Features dustproof covers and heavy-duty construction.
The fitting mechanism allows installation into interior or exterior panels including steel and aluminium.

Specifications:
Blue LED
Input voltage: 12V-24V ± 4.0V
Amperage Rating: 20A at 12VDC, 10A at 24V
Voltage range: 8V-32V
USB Type-A Output: QC3.0 Max 36W
USB Type-C Output: QC4.0. Max 60W
Over Voltage Protection: Yes
Over Current Protection: Yes
Over Temperature Protection: Yes
Short Circuit Protection: Yes
Reverse Polarity Protection: Yes
Size: 60mm x 43mm
Mounting Depth: 57mm
Mounting opening: 29mm Diameter (per socket)
Supplied with terminals & screws
Packaging: Heat sealed blister and card with hang hole
