Modular AMI/Midi Fuse Holder

Modular AMI/Midi Fuse Holder

This modular AMI/MIDI fuse holder designed for high-current DC applications, providing a secure and flexible solution for circuit protection.
Its linkable design allows seamless integration using DNA MIDIBB busbars, creating a compact and customisable fuse distribution system ideal for automotive, marine, caravan, and off-grid power setups.

Features:

Modular, linkable design for multi-fuse setups
Works with MIDI010-N input module

High-current capability for heavy-duty circuits

Protective cover for safety and durability

Compatible with busbars and input modules

Specifications

Fuse Type: MIDI / AMI

Maximum Voltage: 24V DC

Maximum Current: 200A per fuse (400A max combined)
Terminal Type: M5 stud connections

Terminal Material: Nickel-plated copper / zinc-plated steel

Housing Material: High-temperature thermoplastic / PBT plastic
Insulated protective cover

Mounting: Surface mount with bolt-down design

Dimensions: 79 x 34 x 26 mm

Operating Temperature: Typically -40°C to +85°C (varies by model)

Also Available:
MIDI010-N - Input Module
MIDI010-5 - 5 Way Module
MIDI010-4 - 4 Way Module
MIDI010-3 - 3 Way Module
MIDI010-2 - 2 Way Module
MIDI010-1 - Single Way Module

Modular Busbar
MIDIBB06 - 6 Holes Busbar
MIDIBB05 - 5 Holes Busbar
MIDIBB04 - 4 Holes Busbar
MIDIBB03 - 3 Holes Busbar
MIDIBB02 - 2 Holes Busbar
