Short Stop Auto Reset Thermal Circuit Breaker - 20 Amp

This single pole thermal type circuit breaker is perfect for installation applications with battery chargers, cars, trucks, buses, RVs, trolling motors, etc
Available as an option is the CBA050C rubber cover which is designed to fit this circuit breaker
Reset: Auto reset
Voltage Range: 12 VDC~24 VDC
SKU
CBA020M
In stock
$15.95
Add to Compare
Fast Shipping
Australia Wide
Australian Owned
& Operated
Secure Checkout
Multiple Payment Options
This single pole thermal type circuit breaker is perfect for installation applications ...
Available as an option is the CBA050C rubber cover which is designed to fit this circui...
Reset: Auto reset
Voltage Range: 12 VDC~24 VDC

Product Overview

Short Stop Auto Reset Thermal Circuit Breaker - 20 Amp This single pole thermal type circuit breaker is perfect for installation applications with battery chargers, cars, trucks, buses, RVs, trolling motors, etc Available as an option is the CBA050C rubber cover which is designed to fit this circuit breaker

Technical Specifications

ResetAuto reset
Voltage Range12 VDC~24 VDC
Rated Current20 Amps
Pole Count1 Pole
Termination2 x #10-32 UNF thread terminals. (Copper terminal for connection to battery. Silver terminal for connection to aux device)
Body MaterialMetal
Cover MaterialBlack thermoplastic cover
Mounting Type90° Chassis mount 49mm long metal bracket with 2 mounting holes (40mm hole centre to hole centre)
Size32mm L x 20mm W x 33mm H
PackagingPoly bag with barcode sticker
