Flush Chassis Mount 3.5mm Stereo Socket and USB to 3.5mm Stereo Plug and USB Audio Data Lead
Flush Chassis Mount 3.5mm Stereo Socket and USB to 3.5mm Stereo Plug and USB Audio Data Lead
Flush chassis mount 3.5mm stereo socket and USB to 3.5mm stereo plug and USB audio data lead
Supplied and fitted with rubber end cap to protect socket when not in use.
Mounting options: Can be flush mounted or can be under dash mounted using the supplied sleeve/bracket.
Fitted with red wire (Positive) and black wire (Negative) for devices like mobile phones to be charged through the USB socket. (For the USB to work properly these wires must be connected to positive and negative 12VDC power)
Flush mounting:
Outer diameter of socket: 34mm
Installation cut out diameter of socket: 30.75mm
Installation mounting depth of socket: 42mm
Mounting with sleeve/ bracket:
Length: 60mm
Height: 37.5mm
Depth: 18mm
Cable length: 1.8 Metres
Cable colour: Black
Pack size: 1 Piece
Packaging: Heat sealed blister and card with hang hole
